Our Services
Audit, Analysis, Research and Development.
Audit & Analysis
This service is split into 3 core areas. (i) Process Evaluation, (ii) Energy Audit, and (iii) Feasibility and Viability Studies.
Process Evaluation
Process Evaluation: The focus of this task is to capture plant or process data either from existing infrastructure or creating new ones. This data will be analysed in-depth with particular focus on performance, efficiency and is highlighting areas of potential improvement.
Energy Audit
Energy Audit: We create comprehensive heat and mass balances, with detailed Process Flow Diagrams for evaluation of existing equipment or processes. Onsite energy audits are tailored to evaluate process efficiency, map heating networks and capture heat losses from entire processes.
Feasibility and Viability Studies
Feasibility and Viability Studies: The aim of such a study is to analyse the technical feasibility of design changes or complete new onsite processes from existing or future plants. The second part of this study evaluates the financial aspect of a new process and looks at capital, operational costs and ROI for the process. These independent studies are ideal for evaluating future CAPEX selection and providing evidence for project sign-off.
Heat Exchanger summary for Lines 1, 2 and 3 combined exhaust @ 55°C
| Design 1 | 5000 kg/h water @ 50 C |
| Design 2 | 7000 kg/h water @ 50 C |
| Design 3 | 9000 kg/h water @ 50 C |
| Design 4 | 11000 kg/h water @ 50 C |
| Design 5 | 13000 kg/h water @ 50 C |
Recovery to water at 50°C gives a good across heat exchanger -> optimal heat recovery to capital cost
| Design 1 | Design 2 | Design 3 | Design 4 | Design 5 | ||
| Heat Load Total | kW | 157 | 220 | 283 | 346 | 408 |
| Heat Exchange Price | £ | £55,000 | £53,000 | £56,000 | £68,000 | £81,000 |
| Gas Savings | £/yr | £25,000 | £34,000 | £44,000 | £54,000 | £64,000 |
Optimal solution -> generating hot water at circa 9000 kg/h
Recovering 280 kW waste heat from exhaust gas on Lines 1, 2 and 3 Driers
| Design 1 | Design 2 | Design 3 | Design 4 | Design 5 | |
| Tubes per bundle | 96 | 93 | 99 | 144 | 84 |
| Tube rows deep | 3 | 3 | 3 | 4 | 4 |
| Tube length (m) | 4 | 4 | 4 | 4 | 4 |
| Tube passes | 12 | 9 | 8 | 9 | 9 |
| Bundles in parallel | 1 | 1 | 1 | 1 | 2 |
| Bays in parallel | 1 | 1 | 1 | 1 | 1 |
| Area, required (m2) | 364.1 | 515.4 | 697.6 | 921.4 | 1196.3 |
| Area, actual (m2) | 697 | 675.2 | 718.8 | 1045.5 | 1219.7 |
| Area ratio (Actual/Reqd.) (*) | 1.91 | 1.31 | 1.03 | 1.13 | 1.02 |
| Pressure drop, outside (Pa) | 182 | 191 | 173 | 197 | 150 |
| Dp ratio outside (*) | 0.91 | 0.95 | 0.86 | 0.98 | 0.75 |
| Pressure drop, tube side (bar) | 0.10702 | 0.09204 | 0.10848 | 0.10089 | 0.10326 |
| Dp ratio tubeside (*) | 0.97 | 0.83 | 0.98 | 0.92 | 0.94 |
| Xflow flow rate (kg/h) | 137162 | 137162 | 137162 | 137162 | 137162 |
| Temperature out - tube side (C) | 50 | 50 | 50 | 50 | 50 |
| Temperature out - outside (C) | 51.02 | 49.44 | 47.85 | 46.31 | 44.87 |
| Heat load total (kW) | 157.1 | 219.9 | 282.7 | 345.6 | 408.4 |
Research and Development Service
EnerTherm Engineering uses the state of the art laboratory situated at the Allia Future Business centre in Peterborough to propose a unique R&D service for companies who do not have the facility to do so or do not have adequate resource. We operate with strict confidentiality agreement. We offer a wide range of services, from rapid prototyping utilising CAE and 3D printing facilities, to complete Virtual Reality immersion which allows the customer to see, touch, and move as if they were in the real world. Our first de-hydrator Factory Acceptance Test was ran virtually. Design optimisation can be done through this service and visualising, touching the final designed product can be achieved in a very quick turnaround.
This is how we conceive new product…
Let's Talk About Your Project
Hi, my name is François and I am passionate about solving process engineering problems.
For the last 20 years, I have been involved in solving and trouble-shooting engineering issues over the world and improved and developed new products and created engineering solutions that improve performance, efficiency, reduce capital and running cost therefore add significant value to customers.
Over the years, I have developed a number of process equipment and control systems which have had significant impact into reducing energy usage, waste and impact on the environment.
My business ethos is to always get to the root cause of problems and data analysis and modelling is always at the fore front of any project we undertake.
At EnerTherm Engineering we have a blend of skills which is ideal for developing, improving new processes or equipment.
Let’s have a quick talk to discuss your requirements and projects. You can get hold of me on 01733 666 701 or use the form and I’ ll get back to you as soon as possible.
